515: 15 Gallon AST Remote Spill Container with Pedastal Mount
www.p65warnings.ca.gov/
The 515 Series remote spill container is a 15 gallon capacity cabinet that provides containment of small spills during tank filling operations.
STANDARD FEATURES
• Single connections in 2”, 3” or 4” female threads
• Dual connections in 2” or 3” (may be combined)
• 15 gallon capacity
• Gas spring cylinder holds the lid in the up position when fueling
• Lockable with a padlock
• Weather-tight enclosure
• Vent cover
• 2 Inch female threaded return pump connection
• 1” NPT drain with locking ball valve
• Base to centerline connection height 30” to 48” pedestal model
• Container 22-1/2” wide x 24” deep x 24-1/4” height
CONSTRUCTION DETAILS
• Container and lid: 12 gauge steel, powder coated white
• Pipe connection: powder coated steel
• Ball valve: brass
• Gasket: Teflon
CERTIFICATIONS & LISTINGS
• CAN-ULC-S663-11; Florida DEP EQ-535
